2108783-2
manufacturer:
TE Connectivity AMP Connectors
Description:
5G/4G/3G/2G, NB-IOT, CAT-M, GNSS
Category:
RF and Wireless
Specifications
Features:
-
Category:
RF And Wireless
RF Antennas
Frequency Range:
698MHz ~ 862MHz, 1.42GHz ~ 1.61GHz, 1.71GHz ~ 2.69GHz, 3.3GHz ~ 3.8GHz
Product Status:
Active
Ingress Protection:
-
Number Of Bands:
4
Mounting Type:
Surface Mount
Package:
Tape & Reel (TR)
Cut Tape (CT)
Series:
-
Antenna Type:
Chip
Mfr:
TE Connectivity AMP Connectors
Frequency Group:
Wide Band
Applications:
CDMA, GSM, LTE
RF Family/Standard:
Cellular
Frequency (Center/Band):
780MHz, 1.515GHz, 2.2GHz, 3.55GHz
Height (Max):
0.125" (3.18mm)
Gain:
4.9dBi, 2dBi, 2.5dBi, 3.2dBi
Termination:
Solder
VSWR:
2
Return Loss:
-
Base Product Number:
210878
Introduction
780MHz, 1.515GHz, 2.2GHz, 3.55GHz CDMA, GSM, LTE Chip RF Antenna 698MHz ~ 862MHz, 1.42GHz ~ 1.61GHz, 1.71GHz ~ 2.69GHz, 3.3GHz ~ 3.8GHz 4.9dBi, 2dBi, 2.5dBi, 3.2dBi Solder Surface Mount
