SRFWG018-150
Manufacturer:
Antenova
Description:
RF ANT 1.561/1.575GHZ FLAT 150MM
Category:
RF and Wireless
Specifications
Features:
Cable - 150mm
Category:
RF And Wireless
RF Antennas
Frequency Range:
1.559GHz ~ 1.609GHz, 2.4GHz ~ 2.5GHz
Product Status:
Active
Ingress Protection:
-
Number Of Bands:
2
Mounting Type:
Adhesive
Package:
Bulk
Series:
Asper
Antenna Type:
Flat Patch
Mfr:
Antenova
Frequency Group:
UHF (1GHz ~ 2GHz), UHF (2GHz ~ 3GHz)
Applications:
Bluetooth, GNSS, Wi-Fi
RF Family/Standard:
Bluetooth, Navigation, WiFi
Frequency (Center/Band):
1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz
Height (Max):
0.006" (0.15mm)
Gain:
5.6dBi
Termination:
U.FL (UMCC), IPEX MHF1 (2)
VSWR:
1.4
Return Loss:
-18dB
Base Product Number:
SRFWG018
Model Number:
SRFWG018-150
Introduction
1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz Bluetooth, GNSS, Wi-Fi Flat Patch RF Antenna 1.559GHz ~ 1.609GHz, 2.4GHz ~ 2.5GHz 5.6dBi U.FL (UMCC), IPEX MHF1 (2) Adhesive
