CD4099BE
Specifications
Part Number:
CD4099BE
Manufacturer:
Texas Instruments
Description:
In Stock. Alternative Models Available.
Lifecycle:
New From This Manufacturer
Datasheet:
CD4099BE Datasheet PDF
Delivery:
DHL、UPS、FedEx、Registered Mail
Payment:
T/T Paypal Visa MoneyGram Western Union
More Information:
CD4099BE More Information
ECAD:
Request Free CAD Models
Pricing(USD):
$0.59
Remark:
Manufacturer: Texas Instruments.
Tanssion Is One Of The Distributors.
Wide Range Of Applications.
Mount:
Through Hole
Height:
5.08 Mm
Weight:
951.693491 Mg
Thickness:
3.9 Mm
Case/Package:
PDIP
Number Of Bits:
8
Output Current:
6.8 MA
Input Capacitance:
5 PF
Propagation Delay:
450 Ns
Max Supply Voltage:
18 V
Number Of Channels:
8
Number Of Elements:
1
Independent Circuits:
1
Number Of Output Lines:
8
Operating Supply Voltage:
3.3 V
Max Operating Temperature:
125 °C
Products Category:
Integrated Circuits (ICs) - Logic - Latches
Datasheet:
CD4099BE.pdf
Qty:
6423 In Stock
Applications:
Body Electronics & Lighting
Motor Drives
Data Center & Enterprise Computing
Width:
6.35 Mm
Length:
19.3 Mm
Polarity:
Non-Inverting
Schedule B:
8542390000
Logic Function:
D-Type, Latch
Number Of Pins:
16
Contact Plating:
Gold
Power Dissipation:
500 MW
Quiescent Current:
100 µA
Min Supply Voltage:
3 V
Number Of Circuits:
2
Turn-On Delay Time:
50 Ns
Number Of Input Lines:
1
Low Level Output Current:
4.2 MA
High Level Output Current:
-4.2 MA
Min Operating Temperature:
-55 °C
Introduction
CD4099BE Overview\\\\nCD4099BE is a model belonging to the Logic - Latches subcategory under Integrated Circuits (ICs). For specific product performance parameters, please refer to the data sheet, such as PDF files Docx documents, etc. We have CD4099BE high-definition pictures and data sheets for reference. We will continue to produce various video files and 3D models for users to understand our product more intuitively and comprehensively. CD4099BE is widely used in Body electronics & lighting,Motor drives,Data center & enterprise computing. It is manufactured by Texas Instruments and distributed by Fans, Tanssion and other distributors. CD4099BE can be purchased in many ways. You can place an order directly on this website, or you can call or email us. At present, We have sufficient supplies. In addition our own stock, we can also adjust the inventory to the peer distributors to meet your needs. If the supply of CD4099BE is insufficient, we also have other models under the Integrated Circuits (ICs) Logic - Latches category to replace it. Fans provides a 1-year warranty to customers who have purchased this part to ensure that our customers have a wonderful purchasing experience and are willing to establish a long-term relationship with Fans. So you can order CD4099BE from Fans with confidence. About delivery, we can deliver goods to our customers through a variety of logistics, such as DHL, FedEx, UPS, TNT and EMS or any other freight forwarder. If you want to know more about the freight, feel free to contact us for more details.
Datasheet PDF
Datasheet PDF
